Klimat K7 Black
181,50 € inc. IVA
21 in stock
Klimat K7 – Seven fans in one
Klimat K7 is a multi-functional fan, developed and manufactured in Sweden, which can be installed both as a bathroom fan or as an energy-saving heat transfer unit. With the multi mode selector it is easy to change between functions: Just lift the cover plate. Select mode. Done!
Bathroom Fan (six selectable ventilation solutions)
Klimat K7 has six selectable operating modes, for performing air extraction in all homes with natural ventilation. It has been designed and approved for installation in wet areas (IP44) such as WCs, bathrooms and utility rooms. For mounting on wall or ceiling (separate, well-insulated ventilation duct Ø 80 – 125 mm).
Heat Mover – save energy
Klimat K7 has an integral electronic thermostat allowing the fan to transfer surplus heat from, e.g. a fireplace, to an adjacent room. The fan is mounted on a partition wall or between floors (wall/floor penetrations Ø100-125 mm). Use ducts and internal grilles. See Klimatfabriken accessories.
Supply air
For good home ventilation you need to ensure that:
– air can enter the wet room by e.g. a larger door gap or an air transfer unit.
– fresh air enters the home through supply air vents in bedroom and living areas.
Additional information
| Weight | 0,66 kg |
|---|
Designation: Bathroom Fan Climate K7 Black
SKU: 50003
GTIN: 7350088510018
E-nr: 9302646
RSK: 8750000
Channel Island: Ø100 mm (Ø80 – 125)
Location: Wall or ceiling
Diameter: Ø175 mm
Depth: 55 mm
Weight: 0.46 kg
Color: Black
Material: Polypropylene (low environmental impact)
Electrical installation: NOTE! All fixed electrical installation must be carried out by a qualified electrician
Capacity, free-blowing:
– Low speed 40 m³/h (11.1 l/s)
– Medium speed 60 m³/h (16.7 l/s)
– High speed 95 m³/h (26.4 l/s)
– Maximum speed 110 m³/h (30.6 l/s)
Max pressure: 48 Pa
Sound pressure level: 17 – 25 dB(A) 3 m
All-pole switch: Yes
Power Consumption: 3W
Voltage/Frequency: 230V AC 50Hz
Connection: Concealed or surface-mounted
Type of motor: BLDC
Protection class: IP44 (range 1)
Insulation class: Class II should not be earthed
Certificate: S – Intertek
Markings: CE
Temperature range: 5 – 35°C
